Cooler Master MasterLiquid Lite 120 Specifications :
| Specification | Details |
|---|---|
| Product Number | MLW-D12M-A20PW-R1 |
| CPU Socket | LGA1700, LGA1200, … , FM2, FM1 |
| Main System Dimensions | 62 x 62 x 36.4 mm / 2.4 x 2.4 x 1.4 inch |
| Main System Power Connector | 4-Pin |
| Waterblock Dimensions | 80.3 x 76 x 42.2 mm / 3.2 x 3.0 x 1.7 inch |
| Pump MTTF | 70,000 Hours |
| Pump Noise Level | < 8 dBA |
| Pump Connector | 3-Pin |
| Pump Rated Voltage | 12 VDC |
| Pump Load Current | 0.3A |
| Pump Power Consumption | 3.96W |
| Radiator Dimensions | 157 x 119.6 x 27 mm / 6.2 x 4.7 x 1.1 inch |
| Radiator Material | Aluminum |
| Fan Dimensions (L x W x H) | 120 x 120 x 25 mm / 4.7 x 4.7 x 1 inch |
| Fan Speed | 650-2000 RPM (PWM) ± 10% |
| Fan Airflow | 66.7 CFM (Max) |
| Fan Air Pressure | 2.34 mmH2O ± 10% |
| Fan MTTF | 160,000 Hours |
| Fan Power Connector | 4-Pin (PWM) |
| Fan Rated Voltage | 12 VDC |
| Radiator Size | 120 |
| Series | MasterLiquid Lite |
| Cooler Type | Liquid Cooler |
